2022 Ace Radiant Tube oven

Description

Specifications: PHYSICAL CONTROLS Inside Dimensions W/O Cart 48"W x 48"D x 59"H Primary Burner - Normal 800°F (427°C) Inside Dimensions With Cart 48"W x 48"D x 45"H Afterburner - Before Primary Ignites 1,400°F (742°C) Volume Over Cart 60 CU. FT. Over Temp. Control Standard Single Platform Cart Dimensions 45"W x 45"D x 14"H Primary Water Spray Standard Outside Dimensions 68"W x 76"D x 70"H Secondary Water Spray Standard Shipping Weight 2,975 LBS. NFPA-86A Specifications Optional Location of Controls Right Side FM Specifications Optional OA-2600 Location of Exhaust Stack Top Rear Left Corner U.L. Listed Control Panel Standard Exhaust Stack I.D. 10" x 10' Included ISO Control Certified Standard Exhaust Stack O.D. 14" x 10' Included Primary Burner off on Loss of A.B. Standard Burners Rated For 800,000 BTU/HR FUEL Automatic Shutoff System Standard Primary Burner Input 90,000 BTU/HR One Touch Control (OTC) System Optional Afterburner Input 425,000 BTU/HR High Fire Afterburner 1,500°F (798°C) Optional Natural Gas Inlet Pressure 8" to 14" W.C. Propane Inlet Pressure 12" to 18" W.C. CONSTRUCTION Gas Inlet Pipe Size 1" Cart Rating 3,200 LBS. Cart 3" Structural Channel 5 LBS/FT ELECTRIC Oven Steel Enclosure 11 Ga. CRS Voltage/Phase/Hertz 120/1/60 Enclosure Front Face 1/4" CRS Plate Amps * 5 to 10 Oven Angle Iron Reinforced Enclosure Standard Blanket Insulation 4" Thick 2,300°F. Standard WATER Aluminized Coating Inside Enclosure Standard Normal Less Than 3.6 Gal/HR. Steel Floor Covers Over 4" Insulation 3/16" CRS Capacity 6 Gal./HR. Ea. Nozzle Exterior Finish Hi-Temp. Blue Enamel Min/Max Pressure 30 to 60 PSI Exhaust Stack Insulation Rated 2,700°F. 2" Thick 1 Top Mounted Pressure Relief Hatch 6.25 SQ. FT. CYCLE TIME/CAPACITY Oven Volume 78.67 CU. FT. 1:12.59 Vent Ratio * Normal Cycle Time 2 to 8 Hours Qty Primary Water Nozzles 2 Standard * Combustible Capacity 40 LBS/HR Qty Secondary Water Nozzles 2 Standard Qty Primary Burners 1 Standard * Varies with the combustible Qty Afterburners
